Flexible Multicore Cable

Flexible Multicore Cable
Flexible Multicore Cable
Send Inquiry
Product Code : 08
Brand Name : Centurion Cables
Product Description

We have emerged as a reputed organization, engaged in manufacturing and supplying best-in-class Flexible Multicore Cable. The offered cable is used in wiring control panels, machines and various electrical installations as these are made using annealed pure bare copper. The Flexible Multicore Cable is insulated with PVC compound, manufactured using high-grade raw materials. These cables are resistant to heat, chemicals, grease and oils therefore widely demanded in the by our customers.

Specifications:

Working voltage Upto 1100 V
Temperature range -15 deg C to +70 deg C
Sizes 0.5 to 4.0 sq mm in two core to 19 cores6.0 to120 sq mm in Three
and Four cores
Color codes Black and Grey outer sheath
2 core cables ‚Red, Black
3 core cables‚Red, Black & Yellow/Green for earth
4 core cables‚Red, Yellow, Blue & Yellow/ Green for earth
5 core cables‚Red, Yellow, Blue, Black & Grey
Any required colors on specific request.
Specification IS 694:1990 NEW CODE: IS: 694/2010
